Hohlwellen Nema 17 Schrittmotor 1.8 Grad 0.25 Nm 1.5 A 4 Drähte Bipolar Hybrid-Schrittmotor
Hohlwellen Nema 17 Schrittmotor 1.8 Grad 0.25 Nm 1.5 A 4 Drähte Bipolar Hybrid-Schrittmotor
Elektrische Spezifikation
- Hersteller #: 17HS13-1504H
- Motorentyp: Bipolar
- Schrittwinkel: 1.8 Grad
- Haltemoment: 0.25 Nm(35.41oz.in)
- Strom: 1.5 A
- Phasenwiderstand: 1.56 ohms± 10%
- Induktivität: 1.9 mH ± 20%(1KHz)
Physikalische Spezifikation
- Rahmengröße: 42 x 42 mm
- Körper Länge: 33.8 mm
- Äußerer Wellendurchmesser: Φ8 mm
- Innenwellendurchmesser: Φ4 mm
- Länge desVorderen Schafts: 16 mm
- Hintere Schaftlänge: 9 mm
- Anzahl Leiter: 4
- Leitungslänge: 310 mm
- Gewicht: 0.23 kg
Verbindung
A+
|
A-
|
B+
|
B-
|
Rot
|
RED/WHI
|
GRN/WHI
|
GRN
|
Ressourcen
Vollständiges Datenblatt: 17HS13-1504H.pdf
Elektrische Spezifikation | |
---|---|
Bipolar/Unipolar | Bipolar |
Haltemoment (Ncm) | 25 |
Haltemoment (oz.in) | 35.41 |
Induktivität(mH) | 1.9 |
Phasenwiderstand(ohm) | 1.56 |
Nennstrom (A) | 1.5 |
Schrittwinkel(°) | 1.8 |
Physikalische Spezifikation | |
Körper Länge(mm) | 33.8 |
Rahmengröße(mm) | 42 x 42 |
Leitungslänge(mm) | 310 |
Anzahl der Leiter | 4 |
Abtriebswellentyp | Hohlwellen |
Einzelne Welle/Doppelwelle | Doppelwelle |
Gewicht(g) | 230 |
- Stecker: Molex, Harwin, Tyco/AMP, JST etc.
- Anschlussdrähte & Kabel: Sonderlängen, Schutzschlauch
- Welle: Rund, D-Cut, Quergebohrt, Keilnut, Gewinde oder Hohl
- Wicklung: Widerstand, Induktivität, Nennstrom, usw.
